WATER RESERVOIR | All have a 1.5 litre stainless steel tank within the chilling chamber to meet peak usage periods. This tank is fabricated for industrial grade 304 stainless steel for your piece of mind. |
REFRIGERATION | All refrigerant gases are non- toxic, non flammable and environmentally sympathetic. The refrigerant flow is controlled by a capillary tube, which has no moving parts. To give me maximum heat exchange a suction line is filled. F2/F3- uses 250 gms of R134a refrigerant
F4/F5- uses 190 gms of R134a refrigerant
F10/F11- 127gms of R22 refrigerant |
WATER FLOW CONTROLS | The bubbler is rated to supply 1.7 l.p.m. at any mains pressure between 140 and 700KPa. An automatic, self- regulating controlled is fitted to overcome varying mains pressure. |
WATER CONNECTIONS | Water inlet- (½”) male B.S.P
Water outlet- 40mm female F.P.V.C. pipe |
TEMPERATURE CONTROL | The thermostat is factory pre- set |
COMPRESSORS | F2/F3- ⅛ hp capacity 138 watts
F4/F5- ⅕ hp capacity 230 watts
F10/F11- ¼ hp capacity 430 watts |
CONDENSER | The condenser is of copper tube and expanded aluminium fin |
ELECTRICAL | 240 volts, 50 HZ. A 2 meter house cable and 3 pin plug is supplied. |
PERFORMANCE TO ARI 1010- 94 STANDARD | Water inlet- 26.7℃
Water outlet- 10℃
Ambient air- 32.2℃
* Approximate figures only |
WEIGHT- PACKED | F2/F3- 26kgs
F4/F5- 28kgs
F10/F11- 30kgs |
DIMENSIONS | Width- 350mm
Depth- 350mm
Height- 1100mm |
WARRANTY | Twelve months comprehensive coverage. Five years for compressor replacement. |
